Cover of volume 101 issue 3

Illustration de couverture :
Essais de nanoindentation (charge maximale 50 mN) réalisés sur le tribofilm formé sur une bille en acier après 1000 cycles de frottement alternatif à une charge normale de 1 N sur un plan de silicium revêtu d'une couche nanocomposite Cu-DLC. Image du fond : observation en microscopie optique du tribofilm sur la bille en acier ; haut : image AFM (signal d'erreur) d'un indent sur l'acier en dehors du tribofilm (10 µm x 10 µm) ; bas : image AFM (signal d'erreur) d'un indent sur le tribofilm (10 µm x 10 µm). S. Bec, J. Fontaine, M. Belin, T. Takeno, H. Miki, article 304 - Photos réalisées au LTDS (Laboratoire de Tribologie et Dynamique des Systèmes)

Caption:
Nanoindentation tests (maximum load 50 mN) on a tribofilm formed on a steel ball rubbed vs silicon wafer coated with Cu-DLC nanocomposite layer (1000 cycles, reciprocating friction test) at 1 N load. Background: tribofilm formed on the ball observed with optical microscopy. Top : AFM observation of an indent on steel outside the tribofilm (error signal, 10 µm x 10 µm). Bottom: AFM observation of an indent on the tribofilm (error signal, 10 µm x 10 µm). The photographs are realised at LTDS (Laboratoire de Tribologie et Dynamique des Systèmes).
